Rcf ART 745-A MK4 15 inç 1400W 2 Yollu Aktif Kabin Hoparlör

SUPERIOR COMPRESSION DRIVERS
The RCF Compression Drivers in pure Titanium are perfect for a crossover point lower than 800 Hz. This allows a better impulse response, fast decay and superior efficiency. Lightweight and powerful, our neodymium drivers are a reference in performance and reliability.
The voice coil features a high-temperature kapton former. The assembly process takes advantage of the RCF proprietary Direct Drive technology. The diaphragm’ s suspension has been designed following extensive studies aimed at minimising distortion and extending low frequency range.

POWERFUL CLASS D AMPLIFIERS
RCF's Class-D power amplifier technology packs huge performance operating with high efficiency into a lightweight solution. ART 7 amplifiers deliver ultra-fast attack, realistic transient response and impressive audio performance. The amplifier features a solid mechanical aluminium structure which not only stabilises the amplifier during transportation but also helps the fan-less heat dissipation. All the ART 7 amplifiers present SMPS power supply section in order to produce maximum output and minimum transportation weight.

BRING ART WITH YOU
The RCF ART 7 Series has earned the prestigious international Red Dot Design Award in the Product Design category. Receiving the renowned Red Dot acts as proof of the excellent design achievements of professionals and up-and-coming talent alike, thus symbolising a seal of quality.

FREQUENCY RESPONSE: 50 Hz ÷ 20000 Hz
MAX SPL @ 1M: 132 dB
HORIZONTAL COVERAGE ANGLE: 90°
VERTICAL COVERAGE ANGLE: 60°
COMPRESSION DRIVER: 1.4" neo, 3.5" v.c
WOOFER: 15", 4" v.c
INPUT SIGNAL: bal/unbal
INPUT CONNECTORS: XRL, Jack
OUTPUT CONNECTORS: XLR
INPUT SENSITIVITY: -2 dBu/+4 dBu
MIC. INPUT SENSITIVITY: -32dBu
CROSSOVER FREQUENCIES: 650 Hz
PROTECTIONS: Thermal, RMS
LIMITER: Soft Limiter
CONTROLS: Volume, Boost, Mic/Line
TOTAL POWER: 1400 W Peak, 700 W RMS
HIGH FREQUENCIES: 400 W Peak, 200 W RMS
LOW FREQUENCIES: 1000 W Peak, 500 W RMS

COOLING: Convection
CONNECTIONS: VDE
CE MARKING: Yes
CABINET/CASE MATERIAL: PP Composite
HARDWARE: 2 x M10
HANDLES: 1 top, 2 Side
POLE MOUNT/CAP: Yes
GRILLE: Steel
COLOR: Black
HEIGHT: 708 mm / 27.87 inches
WIDTH: 437 mm / 17.2 inches
DEPTH: 389 mm / 15.31 inches
WEIGHT: 18.8 kg / 41.45 lbs
PACKAGE HEIGHT: 750 mm / 29.53 inches
PACKAGE WIDTH: 500 mm / 19.69 inches
PACKAGE DEPTH: 440 mm / 17.32 inches
PACKAGE WEIGHT: 22 kg / 48.5 lbs
